hp compaq d530

Technické parametry

Model : HP d530 SFF(DC578AV)
Procesor: P4 2.66GHz
Memory: 256MB

Chipset 1 Model : Hewlett-Packard Company 82865G/PE/P, 82848P DRAM Controller / Host-Hub Interface
Front Side Bus Speed : 4x 133MHz (532MHz data rate)
Maximum FSB Speed / Max Memory Speed : 4x 200MHz / 2x 200MHz
Width : 64-bit

Více viz zde

Identifikace pod Linuxem

[lspci]

00:00.0 Host bridge: Intel Corp. 82865G/PE/P Processor to I/O Controller (rev 02)
00:02.0 VGA compatible controller: Intel Corp. 82865G Integrated Graphics Device (rev 02)
00:1d.0 USB Controller: Intel Corp. 82801EB USB (rev 02)
00:1d.1 USB Controller: Intel Corp. 82801EB USB (rev 02)
00:1d.2 USB Controller: Intel Corp. 82801EB USB (rev 02)
00:1d.7 USB Controller: Intel Corp. 82801EB USB2 (rev 02)
00:1e.0 PCI bridge: Intel Corp. 82801BA/CA/DB/EB PCI Bridge (rev c2)
00:1f.0 ISA bridge: Intel Corp. 82801EB LPC Interface Controller (rev 02)
00:1f.1 IDE interface: Intel Corp. 82801EB Ultra ATA Storage Controller (rev 02)
00:1f.2 IDE interface: Intel Corp. 82801EB Ultra ATA Storage Controller (rev 02)
00:1f.5 Multimedia audio controller: Intel Corp. 82801EB AC'97 Audio Controller (rev 02)
05:02.0 Ethernet controller: Broadcom Corporation NetXtreme BCM5782 Gigabit Ethernet (rev 03)

[výběr z dmesg]

Detected 2660.213 MHz processor.
Memory: 247216k/253888k available (1508k kernel code, 6284k reserved, -1961k data, 156k init, 0k highmem, 0k BadRAM)
CPU: L2 cache: 512K
..... CPU clock speed is 2660.1249 MHz.
..... host bus clock speed is 133.0060 MHz.
PCI: PCI BIOS revision 2.20 entry at 0xec5a9, last bus=5
isapnp: Scanning for PnP cards...
isapnp: No Plug & Play device found
Linux NET4.0 for Linux 2.4
Serial driver version 5.05c (2001-07-08) with HUB-6 MANY_PORTS MULTIPORT SHARE_IRQ SERIAL_PCI ISAPNP enabled
ide: Assuming 33MHz system bus speed for PIO modes; override with idebus=xx
hda: ST340014A, ATA DISK drive
hdc: MITSUMI CD-ROM FX48++M, ATAPI CD/DVD-ROM drive
hda: 78165360 sectors (40021 MB) w/2048KiB Cache, CHS=5169/240/63, UDMA(100)
Initializing Cryptographic API
IP Protocols: ICMP, UDP, TCP, IGMP
input: USB HID v1.10 Mouse [Logitech Optical USB Mouse] on usb3:2.0
Broadcom Gigabit Ethernet Driver bcm5700 with Broadcom NIC Extension (NICE) ver. 6.2.11 (05/16/03)
eth0: Broadcom NetXtreme Gigabit Ethernet for hp found at mem fc500000, IRQ 20, node addr 000d9dd135be
eth0: Broadcom BCM5705 Integrated Copper transceiver found
eth0: Scatter-gather ON, 64-bit DMA ON, Tx Checksum ON, Rx Checksum ON, 802.1Q VLAN ON, NAPI ON
inserting floppy driver for 2.4.22-10mdk
Floppy drive(s): fd0 is 1.44M
hdc: attached ide-cdrom driver.
hdc: ATAPI 48X CD-ROM drive, 128kB Cache, DMA
Uniform CD-ROM driver Revision: 3.12
bcm5700: eth0 NIC Link is UP, 100 Mbps full duplex
Linux agpgart interface v0.99 (c) Jeff Hartmann
agpgart: Maximum main memory to use for agp memory: 196M
agpgart: Detected an Intel(R) 865G Chipset.
agpgart: Detected 8060K stolen memory.
agpgart: AGP aperture is 128M @ 0xf0000000

Postup zprovoznění pod Linuxem

Běžná instalace Mandrake 9.2
Gentoo Linux
Debian 7.3 s prostředím xfce

Poznámka

Počítač je certifikován pro Mandrake 9.1

Teplota při běžném provozu v kanceláři:
Board Temperature : 41.0°C
CPU Temperature : 37.0°C
Power / Aux Temperature : 48.0°C
HD / Aux Temperature : 44.0°C

Quake III Benchmark
Nastavení: 800x600, nic moc detaily, v konzoli pak "timedemo 1" a "demo four", počítám až výsledek z druhého průchodu timedema
1260 frames, 99.4 seconds, 12.7 fps

Updatováním je možné do BIOSu přidat zajímavé funkce např. automatické zapnutí PC v určitý čas.

Obrázky
